Flash 100

​​This is a Leg​acy product and has been discontinued.

However, Teledyne SSI will continue to provide spare parts and service.​​

Flash 100 Legacy HPLC Pump

A Versatile Pump Designed Specifically for Flash Chromatography Applications.

Wide, Accurate Flow & Pressure Range

The Flash 100 Pump has been designed specifically for Flash Chromatography applications. The unit provides a wide range of flow rates and consistent performance to minimize the potential for column damage.

The Flash 100 offers easy solvent changeover and priming capability. In addition, the unit provides accurate and predictable flow characteristics over the available pressure range.

High Performance at a Low Cost

The use of modern digital stepper motor technology provides the performance of the most expensive pumps at an exceptional value. The pump includes a 3-year warranty.

Control Option

RS232 and a Run/Stop connector available.

Easy Maintenance

In addition to the proven reliability, the Autoflush™ piston wash and easy seal change procedures keep maintenance costs low.

Replaced by LD Class HPLC Pumps
Pump Flash 100

Standard Features

  • Prime purge valve
  • Pressure monitoring
  • Autoprime™ one button toggles flow rate to maximum for rapid solvent change
  • Front panel flow adjustment: 0.1 mL/min. increments
  • Digital stepper motor design prevents flow rate drift over time and temperature.
  • Run/stop inputs (5 volt TTL type)
  • 0 to 10 volt, 0 to 10 KHz flow rate control input
  • RS232 serial communications port for complete control and status monitoring
  • USB Connectivity (Integrated USB to RS-232 Solution)
  • External Run/Stop control via Contact or TTL

Flash 100 HPLC Pump Specifications

Flow Rates0.1 – 100.0 mL/min.
Pressure>0 – 1000 PSI
Pulsation ± 4% @ 50 mL/min. and 250 PSI
Pressure Zero Offset± 2 PSI
Flow Accuracy± 2%
Flow Precision0.5% RSD
Dimensions 5.5” H x 10.5” W x 17.5” D (14 x 26 x 44.5 cm)
Weight 13.6 lbs. (30 Kg)​
